McIntosh Titan 800

The Titan Wagon features heavy duty 13mm floor and elevator chains and larger diameter sprockets which are designed to handle large and heavier volumes of material with ease. Larger floor and elevator shafts and bigger gearboxes are all designed to give trouble free operation and extended service life, with less time needed adjusting chains.

12.4m3 with a level load
75 x 40 channel floor slats
Gearbox on floor drive with 50mm high tensile floor shaft
2 x 13mm floor chains with a breaking point is 23 Tonne
2 elevator chains
3mm pressed steel sides
5mm steel floor
1200mm wide conveyor belt
Bolt on floor slats, elevator slats welded
Bolt on mudguards
Cast iron bearing bronze bushes for longer life
Fully welded construction
Rear idler remote grease lines
LED rear lights
Grease hose from walking beam to mudguard
High quality paint system
Ladder
Dummy load cells
140mm diameter conveyor roller
Plate towing eye 32mm thick 40mm eye
Proven vertical elevator system with adjustable
angle
Tandem oscillating axle with 70mm 6 stud hubs
Tracking strips on cross conveyor
Tyre size 12.5/80-15.3 6 stud

Extras included
Auto adjusting floor chains
